Product Development

We propose optimal product specifications that meet the required performance using materials developed in-house.

#Drawing CAD and CAE Analysis

We understand the behavior of the product when it is used (fastening + internal pressure load), conduct preliminary examination of prototype specifications (parameter study), and establish optimal specifications.

#

#Contact Pressure by Fuji Impression Paper

We use Fujifilm's pressure measurement film (Prescale) to visually assess surface pressure distribution when fastening parts. By converting scanned film data into digital numbers, we verify specification differences, evaluate seal performance, and confirm design concept validity.

#Pressure Image Analysis System (FPD-8010J)

#

#Digital Conversion of Generated Surface Pressure

#

#3D Display of Generated Surface Pressure

#

#Analysis and Evaluation Testing

Engine Durability Bench Room/Test Room

We set severe operating conditions and evaluate the toughness of parts when installed in an actual vehicle. (Located in the Tochigi R&D Center)

Chassis Dynamo Equipment for Motorcycle (45kW)
#
Bench-mounted Durability Equipment for Automotive Engine (220KW AC-DY)
#
Universal (tension/compression) Testing Machine

Used for various characteristic tests.
Load cell: 100kN (tension/compression), 1kN (tension)

#
Hydraulic Servo Type Fatigue Testing Machine (single axis)

Verifies material toughness.
Load cell: 100kN
(under load at temperatures up to 250℃)

#
Hydraulic Servo Type Fatigue Testing Machine (biaxial)

Verifies the wear resistance of materials.
Load cell: 100kN (vertical and horizontal)
Can slide under load at temperatures up to 150°C

#
Digital Microscope

Magnified observation of parts and materials

#
TG / DTA

Simultaneous evaluation of mass change due to temperature change and heat absorption and generation

#
Curastometer

Acquisition of vulcanization characteristics of compounded rubber

#
